  • Noise Level



    Noise Level

    U.S
    Metric





    Sound power
    105 dBA




    Sound pressure
    73 dBA




    Specifications are general and subject to change without notice. If exact measurements are required, equipment should be weighed and measured. Due to selected options, delivered equipment may not necessarily match that shown.



  • Water System



    Water System

    U.S.
    Metric





    Water tank capacity
    200/400 gal
    757/1514 L



    Water pump flow
    4.2 gpm
    15.9 l/min



    Water pump pressure, max
    3,000 psi
    207 bar



    Clutch type
    Electric pump clutch w/auto de-clutch




    Antifreeze system
    50/50 water/antifreeze




    Hose reel (locking)
    50 ft
    15.3 m

  • Hydraulic System



    Hydraulic System

    U.S.
    Metric





    Reservoir size
    4.2 gal
    15.9 L



    Pressure
    2,500 psi
    172 bar



    Tank dump cylinders
    2.5 in
    63.5 mm

  • Superior Support
    FXT30
    Superior Support

    Your Ditch Witch equipment is backed by a worldwide network of dealers you can count on for unmatched commitment to your success. From genuine Ditch Witch parts to factory-trained service to expert advice, your Ditch Witch dealer has it all for you.

  • Battery



    Battery

    U.S.
    Metric





    SAE reserve capacity rating
    110 min




    SAE cold crank @ 0°F (-18°C)
    800 amps




    Electrical system
    12V


  • Power
    FXT30
    Power

    Equipped with a 24.8-hp (18.5-kW) Kubota® diesel engine, the FXT30 offers 576 cfm (16.3 m3/min) of suction power and outstanding water pressure.

  • Versatility
    FXT30
    Versatility

    Mounts to single-axle truck of your choice, new or used, so you can control the level of initial investment and customize with toolboxes and support equipment; complies with all truck manufacturers’ requirements.

    Choice of 500-gallon (1893-L) spoils tank with 200-gallon (757-L) water tank or 800-gallon (3028-L) spoils tank with 400-gallon (1512-L) water tank to meet the requirements of virtually any size cleanup job.

  • Productivity
    FXT30
    Productivity

    Easy access to power pack for convenient servicing.

    Optional heater keeps water system from freezing in inclement weather and increases production in tight soils.

  • Vacuum System



    Vacuum System

    U.S.
    Metric





    Air flow
    500 cfm
    14.2 m3/min



    Drive type
    Belt




    Vacuum, max
    15 in Hg
    381 mm Hg



    Vacuum tank capacity
    500/800 gal
    1893/3028 L



    Full opening door diameter
    52 in
    1320.8 mm



    Tank outlet valve size
    6 in
    152.4 mm



    Tank inlet valve size
    4 in
    101.6 mm



    Tank dump angle, max
    45°




    Primary shut-off (ball type)
    12 in
    304.8 mm



    Filter type
    Washable polyester




    Filter area
    100 ft2
    9.3 m2



    Filter rating
    0.5 micron per ASHA RP531




    Hose
    3 in
    76.2 mm

  • Ease of use
    FXT30
    Ease of use

    Easily accessible controls and service points; curbside controls can be configured for left- or right-hand traffic, for greater safety and convenience.

    Remote-fill water tank allows for easy filling and prevents siphoning back into the water supply.

    Integrated tool rack on door and underbody hose storage help simplify operation.

    Ladders provide easy access to truck bed, and can be stowed when not in use.

    Optional hydraulic boom extends to 14 ft (4.3 m); saves labor, time and reduces operator fatigue.

    Optional reverse-flow feature enables quick and easy offloading of spoils.

    Standard hydraulic door opens fully horizontal to maximize the efficiency of spoils removal; door also features hydraulic locks.

    Autoclutching feature disengages the water pump when water is not in use, allowing full system power for suction.

  • Power



    Power

    U.S.
    Metric





    Engine
    Kubota® D1105-E3B




    Fuel
    Diesel




    Cooling medium
    Liquid




    Injection
    Indirect




    Aspiration
    Natural




    Number of cylinders
    3




    Displacement
    68.6 in3
    1.12 L



    Bore
    3.07 in
    78 mm



    Stroke
    3.09 in
    78.5 mm



    Manufacturer's gross power rating (SAE J1995)
    25 hp
    18.5 kW



    Rated speed
    3,000 rpm




    Emissions compliance
    EPA Tier 4
    EU Stage IV



    Fuel tank capacity
    15 gal
    56.8 L

  • Dimensions (vac only)



    Dimensions (vac only)

    U.S.
    Metric





    800 Gal Spoils/400 Gal Water





    Length
    214.3 in
    5443.2 mm



    Width
    96 in
    2438.4 mm



    Height
    93 in
    2362.2 mm



    Weight, empty
    5,910 lb
    2680.7 kg



    Truck GVWR, min
    33,000 lb
    14968.5 kg



    500 Gal Spoils/200 Gal Water





    Length
    214.3 in
    5443 mm



    Width
    96 in
    2438 mm



    Height
    93 in
    2362 mm



    Weight, empy
    5,400 lb
    2449.4 kg



    Truck GVWR, min
    25,950 lb
    11770.7 kg



    800 Gal Spoils/400 Gal Water (Tandem Axle)





    Length
    235.3 in
    5976.6 mm



    Width
    96 in
    2438.4 mm



    Height
    93 in
    2362.2 mm



    Weight, empty
    6,410 lb
    2907.5 kg



    Truck GVWR, min
    5,200 lb
    23586.8 kg

  • Rugged design
    FXT30
    Rugged design

    Designed specifically for mounting on truck frame rails, allowing system components to flex independently of truck, for maximum structural integrity.

    Designed for minimal overall package height, resulting in a lower center of gravity and better handling during transport.

    Saddle-style tanks provide optimal weight distribution to keep payload over rear axle.

    Reusable, 0.5-micron washable vacuum filter and a blower relief valve air filter provide the industry's best filtration; optional cyclonic filter cleans the air before it reaches the filter, minimizing maintenance.

  • Operator Comfort
    FXT30
    Operator Comfort

    The 73-dBA FXT30 is one of the quietest vacs on the market; fully enclosed, insulated and lockable power pack protects major components from weather and vandalism while leading the industry in noise reduction.
