  • Chain Force - Tier 3
    • First Gear63,405 (282)
    • Second Gear29,882 (133)
    • Third Gear20,550 (91)
    • Fourth Gear13,503 (60)
    • Fifth GearN/A
    • Reverse Gear74,963 (333)
  • Engine Tier 3
    • Engine MakeCAT
    • Engine ModelC9 Tier 3, Stage IIIA
    • Power HP (Kw)350 (261) @ 2200 RPM
    • Torque FT-LBS (Nm)1148 (1156) @ 1400 RPM
    • U.S. GAL/hr (L/hr) Full Power18.6 (70.4)
    • Fuel Capacity U.S. GAL. (L)265 (1003)
    • Hydraulic Capacity U.S. GAL. (L)167 (632)
    • Hours per full tank - full power14.2
    • TransmissionAllison 4500
    • Variable-Reversing Engine Cooling FanHydraulic Drive
  • Ground Specs
    • Ground Speed Low
      - MPG (KM/H)
      0.6 (0.9)
    • Drawbar Pull Low (Max)
      - LB (KN)
      132,161 (588)
    • Ground Speed High (Max)
      - MPH (KM/H)
      1.7 (2.7)
    • Drawbar Pull High
      - LB (KN)
      46,857 (208)
    • Ground Bearing No Attach
      PSI (BAR)
      10.88 (0.75)
  • Engine Tier 4 Final
    • Engine MakeMTU
    • Engine Model6R1100C30 TIER 4 FINAL
    • Power HP (Kw)375 (280) @ 1700 RPM
    • Torque FT-LBS (Nm)1401 @ 1300 RPM
    • U.S. GAL/hr (L/hr) Full Power17.3 (65.5)
    • Fuel Capacity U.S. GAL. (L)265 (1003)
    • HYD Capacity U.S. GAL. (L)167 (632)
    • Hours Per Full Tank - Full Power15.3
    • TransmissionAllison 4500
    • DEF Capacity U.S. GAL. (L)25.4 (95)
    • Variable- Reversing Engine Cooling FanHydraulic Drive
  • Standard Attachments - In (mm)
    • Boom Width13 (330) 1-D8
    • Trench Width X Max Depth16-24 (406-610) X 12'
    • Boom Width21 (553) 2-D6x10 (254)
    • Trench Width X Max Depth24-36 (610-915) X 10'
    • Primary Boom Depth - FT (M)6.5 (1.98)
    • Boom Extensions - FT (M)2 (.61), 4 (1.22)
    • Standard Digging Depths - FT (M)6-12 (1.83-3.66)
  • Chain Speed - FT/MIN - Tier 3
    • First Gear173 (53)
    • Second Gear367 (112)
    • Third Gear534 (162)
    • Fourth Gear813 (248)
    • Fifth GearN/A
    • Reverse Gear146 (45)
  • Weights - LB. (Kg)
    • MINIMUM OPERATING WEIGHT90,000 (40,823)
    • MAXIMUM OPERATING WEIGHT110,000 (49,895)
    • SHIPPING WEIGHT (NO CWT, BOOM, TRACKS)70,000 (31750)
    • UNDERCARRIAGE WT TOTALN/A
    • COUNTERWEIGHT TOTALN/A
  • Chain Force - LB (KN) - Tier 4 Final
    • First Gear87,915 (391)
    • Second Gear41,433 (184)
    • Third Gear28,494 (127)
    • Fourth Gear18,722 (83)
    • Fifth Gear14,310 (64)
    • Reverse Gear103,941 (462)
  • Dimensions - In (mm)
    • MACHINE LENGTH, NO ATTACHMENTS316.4 (8037)
    • MACHINE WIDTH, NO ATTACHMENTS98.7 (2507)
    • MACHINE OVERALL WIDTH98.7 (2507)
    • MACHINE OVERALL HEIGHT133.4 (3388)
  • Chain Speed - FT/MIN (M/MIN) - Tier 4 Final
    • First Gear134 (41)
    • Second Gear284 (87)
    • Third Gear413 (126)
    • Fourth Gear628 (191)
    • Fifth Gear822 (250)
    • Reverse Gear113 (34)
